Description
Short Description
High‑capacity commercial refrigerated air dryer designed for reliable moisture removal in compressed air systems up to 45 CFM.
Full Description
The SMC IDFB8E‑11N Commercial Refrigerated Air Dryer is engineered to deliver consistent, high‑efficiency moisture removal for medium‑to‑large compressed air systems. With an airflow capacity of 41–45 CFM, this model is ideally suited for industrial and commercial applications using 7.5–10 HP air compressors, where clean, dry compressed air is critical to equipment reliability and process quality.
Using proven refrigerated air drying technology, the IDFB8E‑11N cools incoming compressed air to condense water vapor, which is then effectively separated and discharged through an integrated automatic drain system. Under rated operating conditions, the dryer maintains a stable outlet pressure dew point of approximately 50°F (10°C), helping prevent condensation, corrosion, and moisture‑related failures in downstream piping, tools, and pneumatic components.
The unit features an air‑cooled condenser, durable industrial cabinet, and compact footprint that allows for easy installation in mechanical rooms and production environments. Designed for continuous indoor operation, the IDFB8E‑11N offers quiet performance, energy‑efficient operation, and low maintenance requirements, making it a dependable solution for protecting compressed air systems in demanding applications.
Applications
- Medium‑to‑large air compressors (7.5–10 HP)
- Industrial pneumatic tools and machinery
- Manufacturing and assembly operations
- Automation and control air systems
- General industrial compressed air networks
Key Benefits
- High‑capacity refrigerated air drying performance
- 41–45 CFM airflow capacity
- Approx. 50°F (10°C) pressure dew point
- Integrated automatic condensate drain
- Protects downstream equipment from corrosion and moisture damage
- Compact, air‑cooled, industrial‑grade construction
- Designed for continuous indoor operation
Specifications (Catalog‑Verified)
- Model: IDFB8E‑11N
- Manufacturer: SMC
- Dryer Type: Refrigerated Air Dryer
- Airflow Capacity: 41–45 CFM
- Rated Inlet Air Temperature: 100°F (37.8°C)
- Outlet Pressure Dew Point: Approx. 50°F (10°C)
- Cooling Method: Air‑cooled
- Power Supply: 115V, Single Phase, 60 Hz
- Operating Pressure: Up to 150 PSI
- Weight: Refer to SMC IDFB Series User’s Manual
- Dimensions: Refer to SMC IDFB Series User’s Manual
User Manual / Technical Documentation
📘 SMC Refrigerated Air Dryer Catalog & User Manual (PDF)
👉 https://schulzproducts.com/wp-content/uploads/2024/03/SMC-DRYER-CATALOG.pdf
Includes installation instructions, electrical wiring details, dimensional drawings, operating conditions, and maintenance procedures applicable to the IDFB8E‑11N.
Warranty
✅ SMC Standard Warranty
- 1‑Year Limited Warranty
Covers defects in materials and workmanship under normal operating conditions.
