Name: SMH 100 High Temp Refrigerated Air Compressor Dryer – 100 CFM, 115V, 194°F
Price: 3199 USD
Availability: InStock

Description

Key Benefits

Handles inlet air temperatures up to 194°F
No external aftercooler required
Energy-efficient refrigeration system
Lower pressure drop
Quiet operation (<70 dB)

Specifications

CFM (use this exact value): 113 CFM
Connections: 1-1/4″ NPT-F
Max PSI: Not specified
Voltage: 115V / 1 Phase / 60Hz
Refrigerant: R134a
Heat Rejection: 6,800 BTU/h
Max Inlet Temperature: 194°F
Max Ambient Temperature: 113°F
Dimensions: 17.5″ x 17.3″ x 35.4″
Weight: 108 lb
Noise Level: <70 dB(A)

Applications

Industrial plants and production lines
Automotive manufacturing
High-demand compressed air systems
Continuous operation environments

Warranty

1 Year Limited Warranty
Extended Warranty Available

Downloads

No downloads available

Frequently Asked Questions

What oil does this compressor use?

Schulz piston compressors use Schulz SG-TM 30 semi-synthetic compressor oil (our SS-30 product). This is the factory-recommended oil for all Schulz L-Series and V-Series piston compressors. Use of other oils may void warranty.

Is shipping included in the price?

Yes — free shipping is included to commercial locations with a loading dock or forklift. Liftgate service, inside delivery, and residential delivery are available for additional fees (shown at checkout). Standard delivery requires a commercial address.

How long does delivery take?

Most compressors ship within 1–2 business days from our warehouse. Delivery typically takes 3–7 business days depending on your location. You'll receive a tracking number when your order ships.

What is covered under warranty?

Schulz compressors include a 2-year warranty on the compressor pump and a 1-year warranty on all other components. Extended warranties (2, 3, or 5 years) are available at checkout. We are an authorized dealer, so all warranty claims are supported directly.

Do I need a special electrical setup?

Single-phase models run on standard 230V single-phase power (common in most shops). Three-phase models require 230V or 460V three-phase service. Always verify your electrical capacity before ordering — our team can help you confirm requirements by phone.

Can I return or exchange the compressor?

Please contact us before purchasing if you have sizing questions — our team can help you choose correctly. For return inquiries, contact us at info@schulzproducts.com or (770)-734-6383 within 30 days of delivery.
