SCHULZ REFRIGERATED AIR COMPRESSOR DRYER – 50 CFM (50-63 CFM)

SCHULZ REFRIGERATED AIR COMPRESSOR DRYER – 50 CFM (50-63 CFM)

$1,269.00

Categories: ,
Share:
Description
Additional Info
Reviews
Description

Schulz ADS 50 Non-Cycling Refrigerated Compressed Air Dryer (50 CFM 115V 1-Phase)

Excellent Performance

  • Even where ambient & inlet temperatures are elevated
  • Nominal air pressure of 100 PSI; 232 PSI maximum

Energy Efficient Sizing

  • Matches the compressor's displacement, saving energy

Electronic Controller

  • Digitally shows temperature & dew point
  • Controls the drain valve through a timer
  • Controls the condenser fan through a probe

High-Efficiency Compressor

  • Circulates the refrigerant through the system

Totally New Design

  • Delivers high dependability & low power consumption
  • Quick disconnect automatic drain valve doesn't need special tools
  • Requires a 115V, single phase circuit

Environmentally Friendly Refrigerant

  • R134a is effective & easier on the environment

Compact Footprint

  • Conveniently sized 18-11/16" x 14-9/16" x 18-11/16"
  • Weighs only 70 pounds; easy to install.
  • 1/2 INCH INLET AND OUTLET PORTS
Additional Info
Reviews

Schulz ADS 50 Non-Cycling Refrigerated Compressed Air Dryer (50 CFM 115V 1-Phase)

Excellent Performance

  • Even where ambient & inlet temperatures are elevated
  • Nominal air pressure of 100 PSI; 232 PSI maximum

Energy Efficient Sizing

  • Matches the compressor’s displacement, saving energy

Electronic Controller

  • Digitally shows temperature & dew point
  • Controls the drain valve through a timer
  • Controls the condenser fan through a probe

High-Efficiency Compressor

  • Circulates the refrigerant through the system

Totally New Design

  • Delivers high dependability & low power consumption
  • Quick disconnect automatic drain valve doesn’t need special tools
  • Requires a 115V, single phase circuit

Environmentally Friendly Refrigerant

  • R134a is effective & easier on the environment
Technical Features
Model ADS 50
Flow (CFM) 50
Rated Pressure (PSI) 175
Maximum Pressure (PSI) 232
Connection (in) 1/2″ NPT-F
Voltage (V) 115
Refrigerant Fluid R134a
Frequency (Hz) 60
Phase Single
Nominal Voltage (A) 3.4
Dimensions (HxWxL in) 19 x 15 x 19
