Schulz ADS 480 Non-Cycling Refrigerated Air Dryer (480 CFM 230V 1-Phase)
Excellent Performance
- Even where ambient & inlet temperatures are elevated
- Nominal air pressure of 100 PSI; 203 PSI maximum
Energy Efficient Sizing
- Matches the compressor’s displacement, saving energy
Electronic Controller
- Digitally shows temperature & dew point
- Controls the drain valve through a timer
- Controls the condenser fan through a probe
High-Efficiency Compressor
- Circulates the refrigerant through the system
Totally New Design
- Delivers high dependability & low power consumption
- Quick disconnect automatic drain valve doesn’t need special tools
- Requires a 230V, single phase circuit
Environmentally Friendly Refrigerant
- R407c is effective & easier on the environment
| Technical Features | |
| Model | ADS 480 |
| Flow (CFM) | 480 |
| Rated Pressure (PSI) | 175 |
| Maximum Pressure (PSI) | 203 |
| Connection (in) | 2-1/2″ NPT-F |
| Voltage (V) | 230 |
| Refrigerant Fluid | R407C |
| Frequency (Hz) | 60 |
| Phase | Single |
| Nominal Voltage (A) | 9.4 |
| Dimensions (HxWxL in) | 44 x 27 x 29 |
